F120 High Mobility Truck
Engineered for extreme terrain and mission-critical operations, this F120 high-mobility 4×4 cab-chassis delivers exceptional performance, durability, and adaptability in the harshest environments. Powered by a robust drivetrain and built on a proven all-terrain platform, it ensures superior traction, stability, and control across mud, sand, water, and steep gradients.
With a modular design that supports a wide range of configurations—from personnel transport to engineering and emergency response—this vehicle combines high payload capacity with operational flexibility. With an approximate curb weight of 6,000 kg and a GVW of 12,000 kg, the F120 provides a strong body-and-payload allowance for mission-specific integration. Designed to keep moving where others stop, it is the reliable backbone for demanding field applications.
Key Advantages

Powerful Performance
330 HP diesel engine with 1200 N·m torque for reliable power in demanding conditions.

All-Terrain Capability
4×4 drivetrain, high ground clearance, and strong climbing ability for extreme environments.

Lightweight Cab-Chassis
Approx. 6,000 kg curb weight with 12,000 kg GVW provides substantial capacity for body integration, equipment and payload.

Bodybuilder
ready chassis architecture supports rescue, command, communications, energy, utility, logistics and other mission-specific bodies.
Applications
This High Mobility Truck is built for demanding industries and mission scenarios:
Emergency Rescue & Disaster Response
Rapid deployment in complex and inaccessible environments.
Special Vehicle & Mission Body Integration
Flexible base platform for rescue, command, communications, energy, utility and logistics bodies.
Oil, Gas & Energy Projects
Reliable access to remote and off-road locations.
Infrastructure & Engineering Support
Transport equipment and crews where road conditions are limited.
Public Safety & Civil Defense
Multi-role platform for firefighting, communication, and logistics.
Specifications
Category | Item | Specification |
General | Model | F120 High-Mobility 4×4 Cab-Chassis |
Drive Form | 4×4 | |
Body Type | Non-load-bearing / cab-chassis platform | |
Occupants | 2 + 12 | |
Electrical System | 24V, negative grounding | |
Dimensions | Overall Dimensions (L × W × H) | 7140 × 2500 × 3180 mm |
Wheelbase | 4180 mm | |
Front / Rear Overhang | 1190 / 1780 mm | |
Approach / Departure Angle | 40° / 37° | |
Mass | Gross Mass | 12,000 kg |
Curb Weight | Approx. 6,000 kg | |
Max Towing Capacity | 5,000 kg | |
Axle Load (Front / Rear) | 5,500 / 6,500 kg | |
Category | Item | Specification |
Performance | Maximum Speed | 110 km/h |
Climbing Gradient | 70% | |
Ground Clearance | 350 mm | |
Turning Radius | 9.5 m | |
Vertical Obstacle | 400 mm | |
Trench Crossing | 700 mm | |
Fording Depth | 1000 mm | |
Driving Range | 600 km | |
Powertrain | Engine | Dongfeng Cummins ISDE6.7-330 Diesel |
Max Power | 243 kW / 2500 rpm | |
Max Torque | 1200 N·m / 1400–1700 rpm | |
Transmission | 6AT Manual-Automatic | |
Transfer Case | Zhuzhou Gear ZQC600-11 | |
Tires | 365/80R20 (Optional CTIS) |
